UNHCR Family Frame Tent


UNHCR/ICRC/IFRC Family frame tent connectable. Made of Poly-cotton Waterproof & Fire retardant optionally. Tent manufacturer Pakistan for humanitarian purpose

Key Features:

  • bell tentNew generation family tent.
  • Bell tentUNHCR/ICRC/IFRC standard
  • BULLETEasy-set up (15 minutes, 3 persons)
  • BULLETFire retardant (optional), waterproof, rotproof and UV-stabilised
Dimension Wall Height Central Height Door
Outer 4×6.60m 125 cm 240 cm 140 cm x 100cm
Inner 3.80×3.95m 115 cm 210 cm 170cm x 100cm


Roof : Poly-cotton 350 g/m2 +/- 15% finished state, 30hPa water penetration, fire resistance. Wall : Poly-cotton 200 g/m2 +/- 10% finished state, 20hPa water penetration, fire resistance. Inner: Poly-cotton 130 g/m2 +/- 10% finished state, fire resistance. Ground Sheet : Laminated Polyethylene (PE) 180 g/m2 +/- 5% finished state, 20hPa water penetration.
Pole Set: Standing pole x3 Ridge pole  x1 Wall  pole x6 Door poles  x4 Windows: windows with mosquito mesh and easy-to-use flap covers. Doors: Doors with loop lace closing system. Ventilation : One Ventilation opening each gable top with closing flap and mesh. Chimney :    One stove pipe Chimney on front vestibule, Size 25cm x 45cm. Accessories: All required resistant tools and accessories including a hammer, steel pegs, steel pins, ropes with runners and assembly instructions.

Packing: Tents are packed in rolled bales with all accessories. Bigger size tents are divided into multiple bales.
Weight: Approx 62 kg
Volume : Approx 0.23 cbm

Without Cage / PALLET
165 units per 20′ GP
300 units per 40′ DC
350 units per 40′ HC

With iron Cage / wooden pallet
120 units per 20′ GP
240 units per 40′ DC
300 units per 40′ HC

  • Inner Partitions
  • winterize kit
  • Custom logo print
  • Color options
  • Wood Stove/Heater

Request More Information About UNHCR Family Frame Tents
