Aim Medical tent system

Emergency Relief Tent

Aim medical tent system is a portable tunnel type tent system suitable for disaster response, medical facility, a field hospital in any area of the world. It can easily accommodate supplies, beds, operation rooms, wards, general checkup, and other treatment facilities as required.
Its ability to connect with the same type of tents makes unlimited possibilities of its usage.

Key Features:

Portable
Clustring connectivity
Adoptable to all weathers

	Size
	5x10m 6x10m 8x10m

Tent Material: Outer : Water repellent Coated Ribstop Poly-cotton fabric 320 GSM (10+/-%) – 2000mm hPa
Inner: Blue Dyed plain Fabric 130 GSM (10+/-%)
Floor sheet: PE laminated fabric 150 GSM (10+/-%)

Groundsheet: PE Groundsheet stitched with the Inner tent in tub style
Poles: Fiberglass Flexible Poles 15mm Diameter (foldable)
Doors: Front and back door with Zip and Mesh door.
Windows: 4 Windows with Mesh and same fabric canvas
Ventilation: 4 Ventilation on roof with mesh
Guy Lines: Supportive ropes on all sides.
Accessories: Ridge Pole, Iron Pegs, Iron Pins, Iron hammer, Repair Kit etc.
Logo Print: AHA Logo printing on selected areas.ns.
